| Input Voltage |
'+10V - +30V DC |
| Active State Current |
100mA (GPS acquisition & GSM transmit mode) |
| Deep Sleep Current |
<3mA |
| Surge Protection |
|
| Digital Inputs |
3 |
| Digital Outputs (relay) |
4 |
| Analog Inputs |
1 |
| Pulse Inputs |
1 |
| IP Rating |
IP54 (IP 65 available upon request) |
| GPS |
L1 1575.42 MHz, 66 Search and 22 Tracking Channels, -162 dBm sensitivity, 2.5m accuracy |
| GSM Bands |
Quad-Band 850/900/1800/1900MHz, GPRS MS Class B, Multi-Slot Class 12 |
| SIM Card Interface |
Micro-SIM |
| GPS Antenna |
Internal |
| GSM Antenna |
Internal |
| Built-in battery backup |
3.7V 800mAh Li-ion |
| Standby |
|
| Storage Temperature |
'-25°C to +70°C |
| Operating Temperature |
'-10°C to +60°C |
| Humididy |
5%–95% non-condensing |
| Mounting |
Flanges |
| Material |
ABS/FRP Plastic |
